Features
Independent Chambers
Kubota's independent dual chamber design allows for two bales to be made simultaneously, effectively cutting the time per bale in half. Doubling your output cuts your field time in half.
Rasspe Knotters
The Kubota small square baler series features the Rasspe 6003 knotter. This rugged single knotter offers tremendous durability while maintaining its performance completing the knotting process in just three tenths of a second, even within the high capacity small square baler.Technology
Featuring real time flake length, flake counters, bale length, hydraulic bale density control, and adjustable target flake length with on board diagnostics, the Kubota small square baler features real time metrics that equip operators with heightened information, that may help lead to a successful season.Twine Capacity
The Kubota small square baler line has two compatible styles of twine storage giving operators both flexibility and adaptability throughout the season. The Kubota small square baler will hold 20 twine spools—five per knotter. As well as the ability to change it to 16 large twine spools—four per knotter—within the easy access compartments on the side of the unit.Wide Pickup
The Kubota small square baler features a wide pickup, capable of handling a variety of sizes of windrow. The wide-pickup ensures a consistent crop feed for both chambers, leaving you with consistent, uniform, and polished square bales.Specifications
Specifications
| Length in. | 280" | |
|---|---|---|
| Width in. | 101.5" | |
| Height in. | 92" | |
| Weight lbs. (kg) | 10,000 (4535) | |
| Diameter Min in. | - | |
| Diameter Max in. | - | |
| Bale Width in. | 12.25"-14" | |
| Bale Height in. | 18" | |
| Bale Formation | Dual Chamber | |
| Endless Belts | - | |
| Bale Ramp | Optional | |
| Working Width in. | 82.5" | |
| Number of Tine Rows | 5 | |
| Tine Spacing in. | 82.5" | |
| Windguard | Chain Adjustable Swath Roller with Tines | |
| Pneumatic Gauge Wheel | Non-Pneumatic, Fixed | |
| Flare to Flare Pickup | 82.5" | |
| Lift | Hydraulic | |
| Pickup Protection | Shear Bolt | |
| Fork Feeder | N/A | |
| Protection, Cam Clutch | N/A | |
| SuperCut-14 Knives | - | |
| Single Knife Protection | - | |
| Unblocking System | - | |
| 1 Main Chain | - | |
| 1 1/4" Main Drive Chain | - | |
| Wide Angle PTO Shaft | - | |
| Shear Bolt Protection | Standard | |
| Cam Clutch Protection | N/A | |
| Binding | Twine | |
| Monitor | TellusGO/ISOBUS | |
| Twine | 20 Balls | |
| ISOBUS | Standard | |
| Focus Terminal | - | |
| IsoMatch Tellus | - | |
| Hydraulic Outlets | - | |
| Wheels and Axles | 11.5/80-15 | - | |
| Wheels and Axles | 15.0/55-17 | - | |
| Wheels and Axles | 19.0/45-17 | - | |
| Wheels and Axles | 500/45-22.5 | - | |
| PTO rpm | 1000 | |
| PTO Protection | - | |
| Minimum PTO Horsepower Required HP/KW | 100 |
